New Yacht

Trawler motor yacht Magellano 66

Aberton Yachts - Azimut Yachts Official Dealer
Leave a request
Download brochure
13
Price
3 535 100
0
VAT
ex-VAT | options included
Length
20.15 m
Built
4Q/2025
Country
Italy
View full specification
Conceived for blissfully reserved sea voyages, the Azimut Magellano 66 complements its crossover character through the possibility of a privacy-oriented onboard design. The large, single-level main deck aptly appeals to diverse lifestyles, offering either a unique open space solution with semi-secluded
Read more
Contact us
You may also contact us in a most convenient form for you - call or write our Manager directly in a messenger to ask your question.
Igor Cherentaev
Yacht Broker
+39 33333 70700
Inspection and sea trial
Inspection and sea trial of Magellano 66 are subject to MYBA terms and conditions. For detailed and up-to-date information on this vessel, please contact us by filling in your contact details in the request form.
We provide
We provide a comprehensive assistance in legal registration of a brokerage transaction, preliminary technical survey, transportation to the required region and re-registration of the vessel in all main registers. You may ask your question in a free format by filling in the form above or by contacting our Manager directly.
Description
Specification
Gallery
Deck plan
Tours
Video
Description
About the yacht


Conceived for blissfully reserved sea voyages, the Azimut Magellano 66 complements its crossover character through the possibility of a privacy-oriented onboard design. The large, single-level main deck aptly appeals to diverse lifestyles, offering either a unique open space solution with semi-secluded flows to lightly separate guests from crew or the Navetta layout for a completely independent galley and wheelhouse.

A timeless beauty. The Magellano 66 perfectly embodies the DNA of the Magellano Collection with elegant lines and a powerful hull, whose bulwarks that rise to protect the side walkways. Below, elongated hullside windows recall nautical tradition with a rounded shape, and, above, wooden louvers positively punctuate the superstructure’s aft end.

The flybridge is a wide, panoramic deck under the sun, with an external helm adjacent the dinette. The flybridge of the Magellano 66 has been enlarged to full beam in the aft part, which can be configured with additional storage and an American bar or left open for freestanding furniture.

In the cockpit, the extended sofa wraps around a vast dining table. There is room for all the guests to gather on this shelteredyet-open-air lookout, and the aft-most backrest can be stowed away to reveal a glass parapet. The infinity terrace effect breaks down the barriers to a clear view of the waves.

Destined for long-range cruising, the Magellano 66 combines comfort and performance for a pleasantly stable life on board. Aiding in her mission, the layout offers airy internal spaces and leaves room for an abundance of storage.

The journey within. The flush main deck welcomes you home to the sea, into a glass house that selects the essentials of sophisticated life. For the occasional indoor meal, the dining table may be extended to host up to eight guests.

The art of daily life. The interior design is characterized by coziness and elegance. Atmospheres that seem suspended in time are the perfect accompaniment for long-range journeys, a balance for harmonious travel with elegantly refined yet warmly welcoming decoration. The storage spaces are studied with an awareness of their essential role, where and how much they are needed.

A unique level of privacy. The main deck layout already separates crew and guest flows, even as a unique open space, protecting the working areas from disturbances. The second layout possibility, named Navetta, takes privacy up a class by completely secluding the galley and wheelhouse area, which can be accessed directly via the side door. True to its name, the Navetta version also allocates additional storage for provisions.

The supremely cozy master suite showcases modern design, such as the pattern of slatted wood behind the head of the bed. A vanity desk port, well served by convenient storage, takes full advantage of the exceptional hull-side windows. On the starboard side, there is a seating area. To properly move the owner in, the suite offers one oversized closet with the height for long dresses and shoes, and a second men’s wardrobe.



Specification
Specification
Price
3 535 100
0
VAT
ex-VAT | options included
Length
20.15 m
Built
4Q/2025
Country
Italy
Shipyard
Material
GRP + Carbon Fibre
Gross tonnage
t
Length overall
20.15 m
Hull length
17.95 m
Waterline length
17.16 m
Beam
0.00 m
Beam overall
5.54 m
Height
0.00 m
Height above waterline
6.34 m
Draft
1.68 m
Draft on keel
1.55 m
Engine
2 x MAN i6 850 hp (625 kW)
Engine hours
m/h
Fuel capacity
4 500 l
Water capacity
1 000 l
Maxspeed
24.00 knot
Speed
19.00 knot
Gray water tank
300 l
Holding tank capacity
300 l
Range
360 nm
Factory ballast capacity
0.00 l
Dry displacement
36.10 t
Displacement
46.40 t
Passenger capacity
14
Berths
6/8 + 2
Cabines
3/4 + 1
Head compartments
3 + 1
Keel
Interior design
Style Dept. Azimut MC
Exterior styling & concept
Style Dept. Azimut MC

Equipment

A detailed technical specification, a list of optional equipment and other commercial information can be provided upon request.
Detailed technical specifications, a list of installed equipment, information about seasonal and maintenance work carried out can be provided upon request.
Detailed technical specifications, a list of available optional equipment, deadlines and ability to make changes in terms of layouts, optional equipment, interior design and other commercial information are provided upon request.
MAIN SYSTEM
  • Cockpit docking station with joystick and thrusters control
  • Proportional stern thruster interfaced with Marex joystick
  • Seakeeper stabilizer 18
  • Watermaker 130l/h
EXTERIOR
  • Bimini on aft flybridge with removable poles
  • Bimini top on bow with removable poles
  • Blue Teak on flybridge
  • Cockpit furniture with refrigerator
  • Dimmered lights on fly
  • Furniture on starboard flybridge with storage (no TV lift)
  • Hard top on fly with electrical awning
  • Luxury lighting package (exteriors)
  • Table in teak at bow convertible in sunbed (hi-low system and cushion included)
  • Telescopic gangway
  • Underwater lights on transom (n.2)
  • Upgraded standard external cushions in Batyline fabric (specify code)
INTERIOR
  • Co-pilot seat in main helm
  • Lower deck lights with dimmer
  • Navetta version, galley and helm station separated
  • Roman blinds with integrated blackout system in cabins (in lieu of standard venetian blinds)
  • Safe in master cabin
  • Toilet with bidet faucet feature (each, specify position)
  • Toilet with bidet faucet feature in crew cabin
  • Wooden floor in salon, galley, helmstation and lowerdeck stairs
APPLIANCES
  • Barbecue on fly
  • Dishwasher in galley
  • Icemaker on flybridge furniture
  • Refrigerator at sight in galley
  • Washer and dryer (two separate units) in lobby
  • Winecooler in salon
ELECTRONICS
  • Raymarine AIS 700
  • Raymarine Gold package
  • Raymarine videocameras n. 3 (CAM220 in cockpit, CAM210 on fly and AX8 in engine room)
VIDEO - TV - HI-FI
  • Smart audio/video package
  • Hi-lo TV mechanism in salon (TV not included)
Deck plan
Flybridge
Flybridge - Alternative layout
Main deck
Main deck - Alternative layout
Lower deck
